1080P Mini Wireless Audio Transmitter

1080P Mini Wireless Audio Transmitter

Video Encoding:	H.265	DC Input:	DC 6V – 17V
Video Input:	HDMI	Bandwidth:	1/2/4/8MHz
Output Power:	200MW	Encryption:	Dynamic 128 Bit AES
High Light:	a mini wireless transmitter, miniature video transmitter

H.265 mini cofdm transmitter HD 1080P Wireless Hdmi UAV Video Transmitter

Product introduction

H.265 COFDM 1080P Micro high definition wireless video transmission equipment, Using the support of nonline of sight (NLOS) transmission and COFDM multi-carrier modulation technology. Using the latest H.265 compression coding method, to improve the coding efficiency and reduce the coding delay, optimization algorithm, anti-error rate, and further improve the image quality, at the lowest rate to achieve the best image compression.

highly integrated embedded design, super linear digital predistortion (Digital Predistortion) RF design, setting network, modulation, and demodulation, and total frequency RF output in one. It can help you to complete the design of long-distance wireless links more conveniently and quickly, and provide high-definition digital broadcasting, security system, public security, armed police, fire-fighting, and other fields.

It is widely used in multi-channel video stream transmission, high-standard unmanned control systems,s, and intelligent control equipment.

Product Features

  H.265 high efficient full high definition 1080P coding compression

 COFDM ultra-narrow band modulation technology

 Supporting nonsight distance (NLOS), high-speed mobile transmission

  Low latency and low power consumption

  Transparent serial port high rate transmission

 Military level nonstandard 128-bit dynamic AES encryption

 Support full band / ultra-narrow band / multi bandwidth modulation (1M/2M/4M/8M)

 OLED high definition digital display panel, simple interface, and easy to operate.

Application

It is suitable for UAV aerial photography, concealed detection, image monitoring, and real-time transmission of wireless images.

Technical characteristics

DC input range	DC 6V – 17V
Working current	550mA_12V/6.6W
Video input	Mini HDMI:1080P/720P
Bandwidth	1/2/4/8MHz
Radio Frequency	300MHz – 1500MHz, stepping 1MHz(other frequencies on request )
Output Power	24dBm/200mW(can customized)
RF interface	MMCX
Encryption	Dynamic 128-bit AES
DATA	Transparent TTL serial data transmission
FEC	1/2,2/3,3/4,5/6,7/8
Guard Interval	1/32,1/16,1/8,1/4
Carries	2K
Video encoding	H.265
Modulation	COFDM
Constellation	QPSK,QAM16,QAM64
Parameter control mode	Through the OLED display panel set the relevant parameters
Dimensions	60mm*36mm*19mm
Weight	58g
