200km manet drone long range udp mimo ip mesh link for drone Wireless Video, Data Telemetry Transmission and Centerless Ad Hoc Networking

200km manet drone long range udp mimo ip mesh link

Description

A 150–200km long-range MANET drone mesh wireless video and data link featuring MIMO, TD-COFDM, IP mesh networking, and centerless self-organizing architecture. Designed for UAVs, public safety, emergency response, and high-speed mobile communications in complex environments.

---

Overview

The 200km MANET Drone Long-Range MIMO IP Mesh Wireless Video & Data Link is a high-performance, centerless ad hoc network transceiver specifically engineered for long-distance, high-mobility, and mission-critical wireless communications.

Based on TD-COFDM modulation, MIMO spatial multiplexing, and IP-based MANET architecture, this system enables real-time video, data, and control transmission over distances of 150–200 km line-of-sight (and up to 520 km configurable at protocol level). It supports point-to-point, point-to-multipoint, and many-to-many networking without relying on any central base station.

The device is optimized for UAVs, drones, emergency networks, public safety, maritime operations, and high-speed mobile platforms, delivering stable broadband connectivity in urban, mountainous, maritime, and aerial environments.

With a compact aluminum enclosure, IP66 protection, strong anti-interference capability, and full customization options, this radio is suitable for both airborne and ground deployments where reliability and flexibility are critical.

---

Features

Advanced MANET Architecture

• Centerless, self-organizing, and self-healing IP mesh network

• Supports Layer 2 / Layer 3 dynamic routing

• Automatic multi-hop relay with star, line, mesh, or hybrid topologies

• No master node or fixed infrastructure required

MIMO & COFDM Technology

• TD-COFDM waveform with adaptive modulation

• Space-time coding and spatial diversity

• TX/RX beamforming and spatial multiplexing

• Adaptive modulation: BPSK to 1024QAM

Ultra-Long-Range Performance

• 150–200 km line-of-sight (air-to-air, open ground)

• Up to 520 km configurable protocol distance

• Receive sensitivity as low as -103 dBm @ 5 MHz

• 5W × 2 RF output power (software-limited to 4W display)

High-Speed Mobility Support

• Doppler tracking up to ±6 kHz frequency shift

• Supports movement speeds up to 7200 km/h (Mach 6)

• Suitable for high-speed UAVs, aircraft, and mobile vehicles

Robust & Reliable Design

• Integrated aluminum heat-dissipation housing

• Shockproof, vibration-resistant, and impact-resistant

• IP66 standard protection (IP67/IP68 optional)

• Operating temperature: -40°C to +80°C

Strong Anti-Interference Capability

• Manual spectrum scanning and channel selection

• Intelligent automatic frequency selection (spectrum sensing)

• Optional adaptive frequency hopping and roaming mode

Secure Communication

• AES-128 / AES-256 encryption

• Optional DES, SNOW3G, ZUC

• Hardware encryption via chip or TF card (customizable)

Full Customization

• Frequency band: 70 MHz – 6 GHz

• Bandwidth: 2.5 / 5 / 10 / 20 / 40 MHz

• Video interfaces, encryption, power levels, and housing colors customizable

---

Applications

Unmanned Aerial Vehicles (UAVs / Drones)

• Long-range drone video transmission

• Swarm drone mesh networking

• UAV command, control, telemetry, and payload data

Public Safety & Law Enforcement

• Mobile surveillance and evidence collection

• Temporary private networks for emergency response

• Rapid deployment in disaster zones

Fire Rescue & Emergency Communication

• Ad hoc broadband networks in collapsed or remote areas

• Real-time video and data sharing among rescue teams

Military & Defense

• Tactical MANET networks

• Vehicle-mounted, airborne, and soldier-carried systems

• Secure and resilient battlefield communications

Maritime & Offshore Operations

• Ship-to-ship and ship-to-shore networking

• Coastal patrol and offshore monitoring

---

Specifications

Radio & Network

• Waveform: Mobile Network MIMO (MN-MIMO)

• Modulation: TD-COFDM

• Adaptive Modulation: BPSK / QPSK / 16QAM / 64QAM / 256QAM / 1024QAM

• Bandwidth: 2.5 / 5 / 10 / 20 MHz (40 MHz optional)

• Data Rate:

  • Up to 100 Mbps @ 20 MHz

  • Up to 180 Mbps @ 40 MHz

Latency

• Average single-hop delay: ~7 ms (20 MHz)

Transmission Distance

• Single hop LOS: 100–200 km

• Urban NLOS: 1–30 km

Power

• RF Output: 5W × 2

• Supply Voltage: DC 9–28V

• Power Consumption:

  • 2×2W: 1–2A working @12V

  • 2×5W: 2–4A working @12V

Networking Capacity

• Unlimited user capacity per system (typically >256 nodes)

• Multi-hop support:

  • Data: 15+ hops

  • Voice: 10+ hops

  • Video: 8+ hops

• Multi-hop bandwidth loss <70%

---

Frequency Band Options

Default Band: 1300–1500 MHz (L-Band)

Optional / Customized Bands:

Special frequency customization may increase cost.

---

Mechanical & Environmental

• Dimensions: 110 × 72 × 32.5 mm

• Weight: ~0.279 kg (2×2W / 2×5W version)

• Housing Colors: Black / Iron Gray / Military Green

• Mounting: 4 mounting holes with ears

---

Interfaces

• 2 × N RF

• 1 × RJ45 Ethernet (100/1000Base-T)

• Wi-Fi

• GPS / Beidou

• 2 × RS232 / TTL (UART)

• SBUS

• DC Power Input

Optional Video Interfaces

• HDMI / SDI / CVBS

• Up to 4K / 2K / 1080P / 720P

---

Network Management

• Web-based GUI management

• Real-time topology visualization

• Signal strength, SNR, throughput, distance monitoring

• GPS/Beidou electronic map display

• Remote silence & wake-up

• SNMP and API for secondary development

---

Field Test Reference

A verified 109 km real-world test was conducted between:

• Point A: Luofu Mountain, Huizhou (1080 m altitude)

• Point B: Zhuhai east coast (3 m altitude)

Configuration:

• Bandwidth: 5 MHz

• TX/RX Power: 2W

• Fiberglass antennas on both ends

Results demonstrated stable video and data transmission with smooth video at 3 Mbps fixed bitrate, confirming long-range performance and link stability.

---

FAQ

Q: Can the air unit remain silent if the ground station does not send data?
A: No. This model does not support silent mode. However, an alternative model with separate uplink/downlink frequencies is available.

Q: What is the gross weight?
A: Approximately 277.5 grams for the 2×5W version.

Q: What is the maximum number of mesh hops?
A: Typically up to 8 hops, depending on signal quality and environment.

Q: Can the second data interface be RJ45 instead of D9?
A: Yes. By removing the internal Wi-Fi module, the device can support two RJ45 Ethernet ports.

---

Customization Options

• Frequency band & bandwidth

• RF power level

• Encryption algorithms

• Video interfaces

• Housing color & labeling

• OEM module versions (10W / 20W)
