ماژول جریان ویدئوی آنالوگ CVBS AHD TVI به شبکه

برنامه های کاربردی

Suitable for CVBS/AHD/TVI analog video to network video stream, analog video to wired network, Wi-Fi network (اختیاری), 4G network(اختیاری), remote video transmission and control.

Default Setting

rtsp://192.168.1.188:554/0

rtsp://192.168.1.188:554/1

User ID: مدیر

رمز عبور: مدیر

امکانات

1. Support H.265, رمزگذاری H.264, ultra-low bit rate, high-definition quality.
2. Support 1920×1080@30/25 frames, 1280*720@30/25 frames, PAL/NTSC analog video input.
3. Support automatic identification and switching of AHD/TVI/CVBS video sources.
4. Support two-way voice intercom.
5. Support RTSP, ONVIF, GB28181, MQTT, WebRtc protocols.
6. Support remote monitoring on mobile phones and PCs, open secondary development SDK.
7. Support DC6~12V/POE power supply.
8. Support wired network, expandable Wi-Fi, 4G network.
9. Support TF card recording up to 256G

مشخصات



Main control	SSC335
Image conversion chip	PR2000K AHD video capture chip
پردازش ویدئو	Supports H.264/H.265 encoding, code rate 0.1M~8Mpbs adjustable, 1~30 frames/second adjustable
Image output	جریان اصلی:1920×1080@30,1280*720@30,720*576@25 Sub-stream:D1, VGA, 640× 360
Audio processing	G.711/ACC encoding, supports two-way voice intercom
Image capture	Supports continuous, timed and triggered capture
Business functions	Support OSD overlay, تشخیص حرکت, humanoid detection, sound alarm
Reset key interface	Supports 1 hardware reset interface
رابط USB	1X USB interface, supports Wi-Fi/4G expansion, customizable UVC function
Network protocol	Supports TCP/IP, IPv4, RTSP, HTTP, DHCP, NTP, RTMP, MQTT, WebRtc
نظارت از راه دور	Supports mobile phone and PC remote monitoring, supports open multi-platform P2P/WebRtc SDK docking
Network interface	1X RJ45 network interface, 10/100M سازگار, lightning protection and anti-static design
Audio interface	Supports 1X MIC input, 1x LINE_OUT
پورت سریال	1 TTL serial port, supports data transparent transmission and IoT device docking
رابط کارت TF	1X TF card interface, maximum support 256G
دمای کاری	-20~70درجه سانتی گراد
Working voltage	DC5.5V-12V, POE power supply
اندازه	Single board 38*38mm (not including lens), special-shaped structure can be customized



Dimension

پرسش و پاسخ

Q1: Does the video encoding board of this CVBS video to network port support two CVBS inputs and two ethernet video streams?

A1: This model does not support two CVBS video inputs and convert to two network video streams at the same time.
Please contact us and I will tell you another model that can support two video streams.

Q2: What is the latency of this video encoder converter board for CVBS video input and IP network stream output?

A2: Please check the test pictures. The delay of this model is not very stable, it will increase the latency with the longer working time.

CVBS camera and monitor displaying needs 93ms.

Q3: Is it possible to add PTZ or serial port data to the video stream? Is it possible to add a logo to the video?

آ: Is WiFi capability required? Need P2P remote access?

We can customize and develop all the functions you mentioned. If your order quantity is more than 500 واحدها, we can do it for free. If it is less than this quantity, we need to charge additional regular development fees.
