30-millisecond Drone UAV HDMI Wireless video transmitter
Ultra-low-latency 30~40 millisecond UAV HDMI Wireless Video Transmitter Drone wireless transmission system for Drone Camera Vcan1729
The latency of a regular COFDM transmitter and receiver is 200-300 milliseconds.
This wireless video transmitter and receiver system has a delay time of less than 30 milliseconds.
Inhaltsverzeichnis
Besonderheit
- Hochintegriert, modulares kombiniertes Design
- Übernehmen Sie die COFDM-Modulationstechnologie
- FPGA-based H.265 video compression technology
- Ultra-low video delay (transmission system delay less than 30 milliseconds)
- Rundum-Kommunikation, keine Angst davor, Mauern zu bauen
- High-speed inter-travel communication,
- Aluminum case with heat sink, shock-proof and impact-resistant
- Keine Sichtverbindung (NLOS) mobile Übertragung, with a distance of not less than 20 Kilometer unter Sichtbedingungen
- Die maximale Bewegungsgeschwindigkeit kann 600 km/h erreichen (gemessen)
- Vollständige Anpassung verfügbar
Anwendung
- It is used for drones that fly at high speed and require a video quality of 1080P.
- This product was mainly used by public security and security inspection departments for technical reconnaissance and forensics.
- Broadcasting includes radio and television live broadcasts, sports broadcasts, soziale Nachrichten, und mehr.
- It is suitable for real-time mobile transmission of high-quality images in urban, Meer, mountain, und andere komplexe Umgebungen.
Spezifikation
UAV HDMI Wireless Video Transmitter
| Modulationsmodus | COFDM |
| Arbeitsspannung | DC11V ~ DC18V |
| Arbeitsstrom | 1 Watts PA:≤1.7A DC12V; 2-Watts PA: ≤2.3A DC12V; 5-Watts PA: ≤3,0A DC12V |
| Steuerschnittstelle | Standard RS232 Interface, 8 Datenbits, 1 Stoppbit, Even Parity, Baudrate: 19200 |
| Transparent Data Interface | Eine einseitige, transparente Übertragung über die serielle Schnittstelle, 8 Datenbits, 1 Stoppbit, Unterstützt ungerade Parität, sogar Parität, drahtlose Parität, Baudrate: 1200, 2400, 4800, 9600, 19200, 38400, 57600,230400 |
| Verschlüsselungsmethode | 128-Bit-AES-Verschlüsselung |
| Modulationszuordnung | QPSK (4QAM), 16QAM, 64QAM |
| Vorwärtsfehlerkorrektur | 1/2 2/3 3/4 5/6 7/8 |
| Schutzintervall | 1/32 1/16 1/8 1/4 |
| Trägernummer | 2K |
| Frequenzbandbreite | 2/3/4/5/6/7/8M verstellbar |
| Transmission Code Stream | 2000kbs~20000kbs einstellbar |
| Transmission Power Amplifier | 1 Watt, 2 Watt, 5 Watt, 10 Watt, 20 Watt (Wir können es für Sie anpassen) |
| Übertragungsfrequenz | can be customized at any frequency, the frequency can be continuously adjusted, step is 1MHz |
| Power Flatness | less than 0.2dB in the 10MHz band |
| Band Shoulder Ratio | the ratio is better than -30dB when the output power is 36dB |
| Second-Harmonic | less than -60Db |
| MER | 32Db |
| Video | 720 50P, 720 60P, 1080 24P, 1080 25P, 1080 30P, 1080 50P, 1080 60P |
| High-Definition Input | HDMI 1080P |
| Video Coding Format | FPGA-based H.265 soft coding |
| Verzögerung | transmission system delay less than 30ms, end-to-end delay |
| Metal | Minimum, Anti-corrosion, anti-vibration design |
| Dimension | 95*75*45Millimeter |
| Gewicht | 0.248kg |
UAV HDMI Wireless Video Receiver
- When the above toggle switch is turned to PC, the serial port data is output from the external red, Weiß, and black three-wire connection, which can be connected to the computer; when it is turned to LCD, the serial port data is output to the LCD screen on the receiver.
- The toggle switch below is the power switch for the LCD screen that comes with the receiver.
| ion mode | QPSK, 16QAM, 64QAM (optional) |
| Vorwärtsfehlerkorrektur | 1/2, 2/3, 3/4, 5/6, 7/8 (optional) |
| number of carriers | 2k, |
| Schutzintervall | 1/32, 1/16, 1/8, 1/4 (optional) |
| Videodekodierung | H.265 |
| Seitenverhältnis | 4:3 16:9 |
| Videobild | 1080P@60P, 50P, 50ICH, 30P, |
| Arbeitsspannung | AC220V/DC12V <0.9EIN |
| Arbeitstemperatur | -20℃~+50℃ |
| Erscheinungsgröße | 480*260* 45 (1U-Chassis) |
| Device Weight | 0.466kg |
Zubehör
FAQs
1. I have a living drone project, do you have zero latency or low delay wireless video transmitter?
This model is our lowest latency for the drone wireless video transmitter and receiver.
It supports the lowest 28-millisecond latency. (Not including the camera and monitor display time)
2. What is the difference between COFDM-912T, COFDM-908T and Vcan1729?
COFDM-912T, CVBS RCA 720P Video Input, 200~400 millisecond.
COFDM-908T: HDMI-Eingang, 200~300 millisecond.
Vcan1729: HDMI-Eingang, 20~40 millisecond. suitable for drone.
Das 1729 model is ultra-low latency, which is very suitable for drones. It can detect obstacles in time, such as houses, Bäume, wires, usw., and avoid them in the shortest time. Many drone factories in China have adopted this video transceiver system.
3. I have a two questions on the HDMI camera input. Does support HDMI 1080i input and HDMI with audio or not?
- Please note that this transmitter only supports HDMI 1080P or 720P input, it does not support HDMI1080i or 720i input.
- In order to decrease the latency delay, the HDMI is not including the Audio signal. Please tell me if you need it, We will make a special firmware for your order, but the latency delay will be longer than HDMI only have video signal.
- Please also note that for the HDMI used by the drone camera, please use extremely thin and anti-interference HDMI cables. Ordinary household HDMI or cheap HDMI cables may cause unexpected failures.
-
What's the distinction between 1080p and 1080i?The two display systems (1080p and 1080i) can both display 1920x1080 pixel images, although they do so in different ways. The letters "ich" und "P" refer to the manner in which the images are displayed. 1080i stands for "interlaced scan" and 1080p is for "progressive scan."
4. How to install your wireless video transmitter and receiver? Any guide?
How to connect Vcan1729, HDMI Wireless Video Transmitter and Receiver
- Please connect the antenna first before you power on the transmitter and receiver, otherwise the Power Amplifier inside is easy to be burned.
- The parameter configuration board tool does not need to connect when you are testing.
parameter configure board tool of lower latency wireless video transmitter and receiver for drone - The power supply of the transmitter and receiver is better to use 12V 3A.
- There is two long receiver antennae and one short antenna for the transmitter. Although you do not need our transmitter antenna, please ensure that the transmitter antenna covers the frequency of 595Mhz. 595Mhz is the center working frequency.
lower latency wireless video transmitter and receiver full set for drone video download link - In the package, there is one HDMI. It is high-quality HDMI cable for drone or robot use.
Ultra-thin and soft HDMI cable for connecting drone HDMI camera and video transmitter - On the receiver, there are two switches on the side. (at the first time to test, please don’t move the switch and no need connect the UART cable to other devices)
Two switch button and UART cable of the wireless HDMI video receiver
PC-LCD: UART cable operate from the computer or LCD on the receiver, there is one LCD menu. If you put the CTRL switch on the LCD side, then the receiver parameter can be adjustable by menu, if you put the CTRL switch on the PC side, then the receiver parameter can be adjustable by computer, you need connect the UART cable to the computer.
LCD power: AUS / on, it can power on or off the small screen on the receiver, after change the receiver parameter, maybe you want to power off the screen displayer to save the power
- For testing, just connect the two receiver antenna on the RF1 and RF2, HDMI output to your HDMI monitor and give it power at 12V
- For testing, just connect the one transmitter on the RF, HDMI cable to connect to your HDMI camera, and give it power at 12V.
- Please contact us if you have any question, or show us the picture or video to us, we will offer you any further information.
Benutzerhandbuch
Laden Sie die chinesische Version herunter
Packaging size:127*27*12CM
Gewicht:8.5KG
