200km manet drone uzun menzilli udp mimo ip örgü bağlantı drone için Kablosuz Video, Veri Telemetri İletimi ve Merkezsiz Özel Ağ İletişimi

200km manet drone long range udp mimo ip mesh link

Açıklama

A 150–200km long-range MANET drone mesh wireless video and data link featuring MIMO, TD-COFDM, IP ağ ağı, and centerless self-organizing architecture. Designed for UAVs, kamu güvenliği, acil müdahale, and high-speed mobile communications in complex environments.

---

Genel Bakış

The 200km MANET Drone Long-Range MIMO IP Mesh Wireless Video & Veri Bağlantısı yüksek performanslıdır, centerless ad hoc network transceiver specifically engineered for long-distance, yüksek hareketlilik, and mission-critical wireless communications.

Dayalı TD-COFDM modulation, MIMO spatial multiplexing, ve IP-based MANET architecture, this system enables real-time video, veri, and control transmission over distances of 150–200 km line-of-sight (ve kadar 520 km configurable at protocol level). Destekler noktadan noktaya, noktadan çok noktaya, and many-to-many networking without relying on any central base station.

The device is optimized for İHA'lar, dronlar, emergency networks, kamu güvenliği, maritime operations, and high-speed mobile platforms, delivering stable broadband connectivity in urban, dağlık, denizcilik, and aerial environments.

With a compact aluminum enclosure, IP66 protection, güçlü anti-parazit özelliği, and full customization options, this radio is suitable for both airborne and ground deployments where reliability and flexibility are critical.

---

Özellikler

Advanced MANET Architecture

• Merkezsiz, kendini örgütleyen, and self-healing IP mesh network

• Supports Layer 2 / Katman 3 dinamik yönlendirme

• Automatic multi-hop relay with star, hat, örgü, or hybrid topologies

• No master node or fixed infrastructure required

MIMO & COFDM teknolojisi

• TD-COFDM waveform with adaptive modulation

• Space-time coding and spatial diversity

• TX/RX beamforming and spatial multiplexing

• Uyarlanabilir modülasyon: BPSK to 1024QAM

Ultra-Long-Range Performance

• 150–200 km line-of-sight (havadan havaya, açık alan)

• kadar 520 km configurable protocol distance

• Receive sensitivity as low as -103 dbm @ 5 MHz

• 5W × 2 RF çıkış gücü (software-limited to 4W display)

High-Speed Mobility Support

• Doppler tracking up to ±6 kHz frequency shift

• Supports movement speeds up to 7200 km / s (Mak 6)

• Suitable for high-speed UAVs, uçak, and mobile vehicles

Sağlam & Reliable Design

• Integrated aluminum heat-dissipation housing

• darbeye dayanıklı, titreşime dayanıklı, and impact-resistant

• IP66 standard protection (IP67/IP68 optional)

• Çalışma sıcaklığı: -40°C ila +80°C

Strong Anti-Interference Capability

• Manual spectrum scanning and channel selection

• Intelligent automatic frequency selection (spektrum algılama)

• Optional adaptive frequency hopping and roaming mode

Güvenli İletişim

• AES-128 / AES-256 şifreleme

• Optional DES, SNOW3G, ZUC

• Hardware encryption via chip or TF card (özelleştirilebilir)

Tam Özelleştirme

• Frekans bandı: 70 MHz - 6 GHz

• Bant genişliği: 2.5 / 5 / 10 / 20 / 40 MHz

• Video interfaces, şifreleme, güç seviyeleri, and housing colors customizable

---

Uygulamalar

İnsansız hava araçları (İHA'lar / Dronlar)

• Uzun menzilli drone video şanzımanı

• Swarm drone mesh networking

• UAV command, kontrol, Arabada veya otobüste 12~24V'yi destekler, ve yük verileri

Kamu güvenliği & Kolluk kuvvetleri

• Mobile surveillance and evidence collection

• Temporary private networks for emergency response

• Rapid deployment in disaster zones

Fire Rescue & Acil Durum İletişimi

• Ad hoc broadband networks in collapsed or remote areas

• Real-time video and data sharing among rescue teams

Askeri & Savunma

• Tactical MANET networks

• Araca monte, havaya ait, and soldier-carried systems

• Secure and resilient battlefield communications

Denizcilik & Offshore Operations

• Ship-to-ship and ship-to-shore networking

• Coastal patrol and offshore monitoring

---

Özellikler

Radyo & Ağ

• Dalga formu: Mobil Ağ MIMO (MN-MIMO)

• Modülasyon: TD-COFDM

• Uyarlanabilir Modülasyon: BPSK / QPSK / 16QAM / 64QAM / 256QAM / 1024QAM

• Bant genişliği: 2.5 / 5 / 10 / 20 MHz (40 MHz isteğe bağlı)

• Veri hızı:

  • kadar 100 Mbps @ 20 MHz

  • kadar 180 Mbps @ 40 MHz

Gecikme

• Average single-hop delay: ~7 ms (20 MHz)

İletim Mesafe

• Single hop LOS: 100–200 km

• Ubban NLOS: 1–30 km

Güç

• RF Çıkışı: 5W × 2

• Besleme gerilimi: DC 9–28V

• Güç tüketimi:

  • 2× 2W: 1–2A working @12V

  • 2×5W: 2–4A working @12V

Ağ Kapasitesi

• Unlimited user capacity per system (tipik olarak >256 düğümler)

• Multi-hop support:

  • Veri: 15+ şerbetçiotu

  • Ses: 10+ şerbetçiotu

  • Video: 8+ şerbetçiotu

• Multi-hop bandwidth loss <70%

---

Frekans Bant Seçenekleri

Default Band: 1300–1500 MHz (L-bandı)

İsteğe bağlı / Customized Bands:

Special frequency customization may increase cost.

---

Mekanik & Çevresel

• boyutlar: 110 x 72 x 32.5 mm

• Ağırlık: ~0.279 kg (2× 2W / 2×5W version)

• Housing Colors: Siyah / Iron Gray / Military Green

• Montaj: 4 mounting holes with ears

---

Arayüzler

• 2 × N RF

• 1 × RJ45 Ethernet (100/1000Baz-T)

• Wifi

• Küresel Konumlama Sistemi / Beidou

• 2 × Rs232 / TTL (UART)

• SBUS

• DC Power Input

Optional Video Interfaces

• HDMI / SDI / CVBS

• Up to 4K / 2K / 1080P / 720P

---

Ağ Yönetimi

• Web-based GUI management

• Real-time topology visualization

• Sinyal gücü, SNR, verim, distance monitoring

• GPS/Beidou electronic map display

• Remote silence & wake-up

• SNMP and API for secondary development

---

Field Test Reference

A verified 109 km real-world test was conducted between:

• Point A: Luofu Mountain, Huizhou (1080 m altitude)

• Point B: Zhuhai east coast (3 m altitude)

Yapılandırma:

• Bant genişliği: 5 MHz

• TX/RX Power: 2W

• Fiberglass antennas on both ends

Results demonstrated stable video and data transmission with smooth video at 3 Mbps fixed bitrate, confirming long-range performance and link stability.

---

SSS

S: Can the air unit remain silent if the ground station does not send data?
bir: Yok hayır. This model does not support silent mode. ancak, an alternative model with separate uplink/downlink frequencies is available.

S: Brüt ağırlık nedir?
bir: Yaklaşık olarak 277.5 gram for the 2×5W version.

S: What is the maximum number of mesh hops?
bir: Typically up to 8 şerbetçiotu, depending on signal quality and environment.

S: Can the second data interface be RJ45 instead of D9?
bir: Evet. By removing the internal Wi-Fi module, the device can support two RJ45 Ethernet ports.

---

Özelleştirme Seçenekleri

• Frekans bandı & Bant genişliği

• RF power level

• Encryption algorithms

• Video interfaces

• Housing color & etiketleme

• OEM module versions (10W / 20W)

Anahtar kelimeler

Drone mesh data link, MANET radio, UAV IP mesh, Uzun menzilli kablosuz video verici, MIMO COFDM radio, centerless ad hoc network, İHA İletişim Sistemi, military mesh radio
