200km manet drone long range udp mimo ip mesh link
Spis treści
Opis
A 150–200km long-range MANET drone mesh wireless video and data link featuring MIMO, TD-COFDM, Sieci kratowe IP, and centerless self-organizing architecture. Designed for UAVs, Bezpieczeństwo publiczne, reakcja awaryjna, and high-speed mobile communications in complex environments.
Przegląd
Plik 200km MANET Drone Long-Range MIMO IP Mesh Wireless Video & Łącze danych to produkt o dużej wydajności, centerless ad hoc network transceiver specifically engineered for long-distance, wysoka mobilność, and mission-critical wireless communications.
Oparte na TD-COFDM modulation, MIMO spatial multiplexing, i IP-based MANET architecture, this system enables real-time video, dane, and control transmission over distances of 150–200 km line-of-sight (i do 520 km configurable at protocol level). To wspiera punkt-punkt, punkt-wielopunkt, and many-to-many networking without relying on any central base station.
The device is optimized for UAV, drony, emergency networks, Bezpieczeństwo publiczne, maritime operations, and high-speed mobile platforms, delivering stable broadband connectivity in urban, górzysty, morski, and aerial environments.
With a compact aluminum enclosure, IP66 protection, silne zdolności przeciwzakłóceniowe, and full customization options, this radio is suitable for both airborne and ground deployments where reliability and flexibility are critical.
cechy
Advanced MANET Architecture
-
Bezcentrowy, samoorganizacja, and self-healing IP mesh network
-
Supports Layer 2 / Warstwa 3 routing dynamiczny
-
Automatic multi-hop relay with star, linia, siatka, or hybrid topologies
-
No master node or fixed infrastructure required
MIMO & COFDM Technology
-
TD-COFDM waveform with adaptive modulation
-
Space-time coding and spatial diversity
-
TX/RX beamforming and spatial multiplexing
-
Modulacja adaptacyjna: BPSK to 1024QAM
Ultra-Long-Range Performance
-
150–200 km line-of-sight (powietrze-powietrze, otwarta przestrzeń)
-
Aż do 520 km configurable protocol distance
-
Receive sensitivity as low as -103 dbm @ 5 MHz
-
5W× 2 Moc wyjściowa RF (software-limited to 4W display)
High-Speed Mobility Support
-
Doppler tracking up to ±6 kHz frequency shift
-
Supports movement speeds up to 7200 km / h (Mach 6)
-
Suitable for high-speed UAVs, samolot, and mobile vehicles
Solidny & Reliable Design
-
Integrated aluminum heat-dissipation housing
-
Odporny na wstrząsy, odporne na wibracje, and impact-resistant
-
IP66 standard protection (IP67/IP68 optional)
-
Temperatura robocza: -40° C do +80 ° C.
Silna zdolność przeciwzakłóceniowa
-
Manual spectrum scanning and channel selection
-
Intelligent automatic frequency selection (wykrywanie widma)
-
Optional adaptive frequency hopping and roaming mode
Bezpieczna komunikacja
-
AES-128 / Szyfrowanie AES-256
-
Optional DES, Snow3g, ZUC
-
Hardware encryption via chip or TF card (konfigurowalny)
Full Customization
-
Pasmo częstotliwości: 70 MHz – 6 GHz
-
Pasmo: 2.5 / 5 / 10 / 20 / 40 MHz
-
Video interfaces, szyfrowanie, poziomy mocy, and housing colors customizable
Aplikacje
Bezzałogowe pojazdy powietrzne (UAV / Drony)
-
Long-range drone video transmission
-
Swarm drone mesh networking
-
UAV command, kontrola, telemetria, i dane ładowania
Bezpieczeństwo publiczne & Organy ścigania
-
Mobile surveillance and evidence collection
-
Temporary private networks for emergency response
-
Rapid deployment in disaster zones
Fire Rescue & Komunikacja w sytuacjach awaryjnych
-
Ad hoc broadband networks in collapsed or remote areas
-
Real-time video and data sharing among rescue teams
Wojskowy & Obrona
-
Tactical MANET networks
-
Zamontowany na pojazd, przewieziony drogą lotniczą, and soldier-carried systems
-
Secure and resilient battlefield communications
Morski & Offshore Operations
-
Ship-to-ship and ship-to-shore networking
-
Coastal patrol and offshore monitoring
specyfikacje
Radio & Sieć
-
Przebieg: Sieć komórkowa MIMO (MN-MIMO)
-
Modulacja: TD-COFDM
-
Modulacja adaptacyjna: BPSK / QPSK / 16QAM / 64QAM / 256QAM / 1024QAM
-
Pasmo: 2.5 / 5 / 10 / 20 MHz (40 MHz opcjonalnie)
-
Prędkość transmisji danych:
-
Aż do 100 MBPS @ 20 MHz
-
Aż do 180 MBPS @ 40 MHz
-
Czas oczekiwania
-
Average single-hop delay: ~7 ms (20 MHz)
Odległość transmisji
-
Single hop LOS: 100–200 km
-
Urban NLOS: 1–30 km
Moc
-
Wyjście RF: 5W× 2
-
zasilanie: DC 9–28V
-
Pobór energii:
-
2× 2 W.: 1–2A working @12V
-
2×5W: 2–4A working @12V
-
Pojemność sieci
-
Unlimited user capacity per system (zazwyczaj >256 węzły)
-
Multi-hop support:
-
Dane: 15+ chmiel
-
Głos: 10+ chmiel
-
Wideo: 8+ chmiel
-
-
Multi-hop bandwidth loss <70%
Frequency Band Options
Default Band: 1300–1500 MHz (Pasmo L)
Opcjonalny / Customized Bands:
| Zespół muzyczny | Zakres częstotliwości |
|---|---|
| UHF | 350–450 / 450–550 / 570–700 / 800–950 MHz |
| Pasmo L | 1000–1200 / 1300–1550 MHz |
| Pasmo S | 1.6–2,5 GHz |
| Pasmo C | 4.4–6.0 GHz |
Special frequency customization may increase cost.
Mechaniczny & Środowiskowy
-
wymiary: 110 × 72 × 32.5 mm
-
Waga: ~0.279 kg (2× 2 W. / 2×5W version)
-
Housing Colors: czarny / Iron Gray / Military Green
-
Montowanie: 4 mounting holes with ears
Interfejsy
-
2 × N RF
-
1 ×Ethernet RJ45 (100/1000Baza-T)
-
Wi-Fi
-
GPS / Beidou
-
2 × RS232 / TTL (UART)
-
SBUS
-
DC Power Input
Optional Video Interfaces
-
HDMI / SDI / CVBS
-
Up to 4K / 2K / 1080P / 720P
Zarządzanie siecią
-
Web-based GUI management
-
Real-time topology visualization
-
Siła sygnału, SNR, przepustowość, distance monitoring
-
GPS/Beidou electronic map display
-
Remote silence & wake-up
-
SNMP and API for secondary development
Field Test Reference
A verified 109 km real-world test was conducted between:
-
Point A: Luofu Mountain, Huizhou (1080 m altitude)
-
Point B: Zhuhai east coast (3 m altitude)
Konfiguracja:
-
Pasmo: 5 MHz
-
TX/RX Power: 2W
-
Fiberglass antennas on both ends
Results demonstrated stable video and data transmission with smooth video at 3 Mbps fixed bitrate, confirming long-range performance and link stability.
FAQ
Q: Can the air unit remain silent if the ground station does not send data?
ZA: Nie. This model does not support silent mode. jednak, an alternative model with separate uplink/downlink frequencies is available.
Q: Jaka jest waga brutto?
ZA: Około 277.5 gramy for the 2×5W version.
Q: What is the maximum number of mesh hops?
ZA: Typically up to 8 chmiel, depending on signal quality and environment.
Q: Can the second data interface be RJ45 instead of D9?
ZA: tak. By removing the internal Wi-Fi module, the device can support two RJ45 Ethernet ports.
Opcje dostosowywania
-
Pasmo częstotliwości & pasmo
-
RF power level
-
Encryption algorithms
-
Video interfaces
-
Housing color & etykietowanie
-
OEM module versions (10W / 20W)
